Specifications

Conformable and reliable Renolit polymeric material. Suitable for full car wrapping (or any other smooth or curved surface).

• The thickness of the film: 0.12mm

• The thickness of film with release liner: 0.28mm

• Type of film: Pressure-sensitive high-grade polymeric vinyl film with air-release channels

• Colors: HM01 Dark grey silk, HM02 Brown grey silk, HM03 Sage silk, HM04 Cameo Pink, HM05 Chiffon green, HM06 Aubergine silk, HM07 Matte Green black silk, SMT02 Burnt Maroon, SMT03 Venetian Violet, SMT04 Boysenberry Black, SMT05 Celtic Green, SMT06 Apollo grey, SMT09 Onyx Grey, SMT10 Solar Orange, SMT11 Surf Blue, SMT12 Paradise Green, SMT13 Pine Green, SMT14 Lawn Green

• Series: 190 series

• Adhesive: Henkel solvent-based acrylic adhesive, transparent, ultra-weather-resistant, viscosity 1000~3000cps, thickness 12 μm dry

• Release liner: Felix Schoeller Release Liner / 20-104-20-1,9 printed, double side PE coated Kraft. One side solventless silicone-coated, air release (ISO 9001, ISO 140001, OHSAS 18001)

• Storing period: 3 years if stored in +10°С to +20°С for optimal quality, relative humidity 50%, in original package, away from direct sunlight, clean and dry place

• Durability/Warranty: Datasheet (Click the link)

• Post heating: 65 Celcius

• Elongation/Break MD:206.8 / CD:196.4 (Test method: ASTM D882-02)
• Tensile Strength: MD:29.5 / CD:24.8 N/mm2 - Speed 200mm/min (Test method: ASTM D882-02)
• Dimensional Stability: 2% - Oven/10'*70C(MD) (Test method: ASTM D1204-02)
• Surface Tension: 34 dynes/cm (Test method: ASTM D2578-04a, 24 hours after production)
• Package:  Roll width 152 cm, length 18 m, weight 13 kg

Install tips:

• Temperature: from +17°-18°С, usage from -45°С to +45°С

• Tools: Standard squeegee with soft (wet) buffer

• Conformability: smooth and medium curved surface

• Directional: yes

• Overlap width: 3-4mm

Important note: The screen's images, colors, and finishes are approximate. For the real representation of the product, always check the color swatch. Rolls from the same production LOT number should be used for completing a wrap job, as a slight batch-to-batch variation of color may occur. The film may scratch during the application or a day in and out use. The scratching of the film is not covered by the warranty.
